RIGOL DS1000Z Series
7 models, list from $319. Compare them, add options and accessories, and request one quote for the lot.
The DS1000Z is the scope a lot of engineers learned on: four channels, 1 GSa/s, 24 Mpts of memory and a 7-inch display at a price that suits a home lab, a classroom or a second bench. RIGOL's UltraVision engine gives it up to 30,000 waveforms a second and a 60,000-frame segmented recorder for catching what happened before you looked.
The Plus models (DS1074Z Plus, DS1104Z Plus) can be turned into 16-channel mixed-signal scopes with RIGOL's MSO upgrade and RPL1116 logic probe. The -S Plus models add a built-in 2-channel 25 MHz waveform generator. The DS1102Z-E and DS1202Z-E are 2-channel versions at 100 and 200 MHz for budgets where four inputs aren't needed.
CH1Models
| Model | Bandwidth | Channels | Description | List price | Quote |
|---|---|---|---|---|---|
| DS1102Z-E | 100 MHz | 2 | 100 MHz Digital Oscilloscope with 2 channels, 1GS/s, 24Mpoint memory | $319 | |
| DS1054Z | 50 MHz | 4 | 50 MHz Digital Oscilloscope with 4 channels plus 24 Mpt memory and 1 GSa/sec sampling | $369 | |
| DS1202Z-E | 200 MHz | 2 | 200 MHz Digital Oscilloscope with 2 channels, 1GS/s, 24Mpoint memory | $389 | |
| DS1074Z Plus | 70 MHz | 4 | 70 MHz Digital Oscilloscope with 4 channels and 24 Mpt memory and connectivity and 1 GSa/sec sampling. Also includes port for logic analyzer for the MSO Upgrade Kit. Future purchase of the MSO Upgrade Kit turns this into a MSO1074Z. | $499 | |
| DS1104Z Plus | 100 MHz | 4 | 100 MHz Digital Oscilloscope with 4 channels plus 24 Mpt memory and connectivity and 1 GSa/sec sampling. Also includes port for logic analyzer for the MSO Upgrade Kit. Future purchase of the MSO Upgrade Kit turns this into a MSO1104Z. | $549 | |
| DS1074Z-S Plus | 70 MHz | 4 | 70 MHz Digital Oscilloscope with 4 channels and 25 MHz 2 channel integrated source plus 24 Mpt memory and connectivity and 1 GSa/sec sampling. Also includes port for logic analyzer for the MSO Upgrade Kit. Future purchase of the MSO Upgrade Kit turns this into a MSO1074Z-S. | $699 | |
| DS1104Z-S Plus | 100 MHz | 4 | 100 MHz Digital Oscilloscope with 4 channels and 25 MHz 2 channel integrated source plus 24 Mpt memory and connectivity and 1 GSa/sec sampling. Also includes port for logic analyzer for the MSO Upgrade Kit. Future purchase of the MSO Upgrade Kit turns this into a MSO1104Z-S. | $769 |
CH2Options and accessories
Software (1)
| Part | Description | List price | Quote |
|---|---|---|---|
| Ultra Station-adv | Full advanced version of UltraStation wave generation software for DG4000 and DG5000 Series generators. This is a software upgrade license | $115 |
Probes (22)
| Part | Description | List price | Quote |
|---|---|---|---|
| PVP3150 | 150 MHz Passive Probe with 1x:10x selector. With bandwidth of 20 MHz in 1x mode | $35 | |
| PVP2150 | 150 MHz Passive Probe with 1x:10x selector. With bandwidth of 35 MHz in 1x mode | $40 | |
| RPL1116 | Standard logic probe for the DS1000Z series. Upgrades a DS1000Z Plus or DS1000Z-S Plus to 16 Digital Channels | $199 | |
| RP3500A | 500 MHz Passive Probe | $231 | |
| RP1300H | 100:1 300 MHz TO 2KV PASSIVE PROBE | $243 | |
| RP1025D | High Voltage Differential Probe, DC-25 MHz, 1400 Vpp | $473 | |
| RP1010H | High Voltage Probe with 40MHz bandwidth, 10kV max DC voltage, 1000:1 | $524 | |
| RP1050D | High Voltage Differential Probe, DC-50 MHz, 7000 Vpp | $683 | |
| RP1100D | High Voltage Differential Probe, DC-100 MHz, 7000 Vpp | $788 | |
| PHA0150 | 70 MHz 1500 V Differential Voltage Probe | $799 | |
| RP1001C | Current Probe, DC-300 kHz, 100 Apeak | $867 | |
| PHA1150 | 100 MHz 1500 V Differential Voltage Probe | $999 | |
| RP1018H | High Voltage Probe with 150MHz bandwidth, 18kV max DC voltage, 1000:1 | $1,038 | |
| RP1000P | RP1003C/RP1004C/RP1005C probe power supply | $1,560 | |
| PHA2150 | 200MHz, 1500V High Voltage Differential Probe | $1,590 | |
| RP1002C | Current Probe, DC-1 MHz, 100A peak | $1,791 | |
| RP1003C | Current Probe, DC-50 MHz, 50A peak. Requires RP1000P power supply. | $3,408 | |
| RP1005C | Current Probe, DC-10 MHz, 300A peak. Requires RP1000P power supply. | $4,332 | |
| RP1004C | Current Probe, DC-100 MHz, 50 A peak. Requires RP1000P power supply. | $4,909 | |
| RP1006C | Current Probe, DC-2 MHz, 500A peak. Requires RP1000P power supply. ≤25mArms noise | $5,490 | |
| PIA1050 | 500MHz optical isolation probe, standard with one 50x and one 2000x attenuator. | $9,999 | |
| PIA1100 | 1GHz optical isolation probe, standard with one 50x and one 2000x attenuator. | $15,199 |
Accessories (7)
| Part | Description | List price | Quote |
|---|---|---|---|
| ADP0150BNC | 50 Ohm impedance adapter for oscilloscopes or generators | $19 | |
| CB-BNC-BNC-MM-100 | BNC Cable (length 1 meter) | $20 | |
| RA5040K | 40 dB attenuator accessory for oscilloscopes or generators | $47 | |
| BAG-DS1000 | Instrument Carry Case for a DS1000 Series Oscilloscope | $69 | |
| RM-DG4000/DS1000Z | Rack Mounting Kit for a DG4000or DS1000Z | $159 | |
| DK-DS6000 | Demo Board for oscilloscopes | $231 | |
| USB-GPIB | USB-GPIB Converter. Connect USB directly to instrument and control it via GPIB. This does not connect to a PC directly | $346 |
Extended warranty (7)
| Part | Description | List price | Quote |
|---|---|---|---|
| DS1054Z (R5-1) | DS1054Z extended warranty, 2 years, option with new product | $32 | |
| DS1074Z Plus (R5-1) | DS1074Z Plus extended warranty, 2 years, option with new product | $42 | |
| DS1074Z-S Plus (R5-1) | DS1074Z-S Plus extended warranty, 2 years, option with new product | $60 | |
| DS1102Z-E (R5-1) | DS1102Z-E extended warranty, 2 years, option with new product | $26 | |
| DS1104Z Plus (R5-1) | DS1104Z Plus extended warranty, 2 years, option with new product | $45 | |
| DS1104Z-S Plus (R5-1) | DS1104Z-S Plus extended warranty, 2 years, option with new product | $63 | |
| DS1202Z-E (R5-1) | DS1202Z-E extended warranty, 2 years, option with new product | $31 |
