RIGOL MSO8074A
750 MHz 4-Channel Mixed Signal Oscilloscope · MSO8000 Series
750MHZ Digital Oscilloscope with 4 channels, 10GSa/sec Sampling
List price $8,799
Quote-only: send the form and we confirm your price, any current RIGOL promotion and the lead time.
Ships within the USA only (50 states, DC, Puerto Rico, Guam, USVI, American Samoa, Northern Mariana Islands). Outside the US? Send an international inquiry
CH1RIGOL MSO8074A at a glance
- 750 MHz of bandwidth on 4 analog channels.
- Up to 10 gsa/s sampling and up to 500 mpts of record length, so long captures keep their detail.
- 600 MHz to 2 GHz on 4 analog channels at 10 GSa/s.
- 500 Mpts memory standard.
- 16 digital channels with the logic probe option.
- 10.1-inch capacitive touch screen; seven instruments in one.
CH2RIGOL MSO8074A specifications
| Figure | MSO8074A | Source |
|---|---|---|
| Part number | MSO8074A | RIGOL |
| Brand | RIGOL | RIGOL |
| Series | MSO8000 Series | RIGOL price list |
| Bandwidth | 750 MHz | rigolna.com |
| Analog channels | 4 | rigolna.com |
| Max. memory depth | 500 Mpts | MSO8000 datasheet |
| Max. real-time sample rate | 10 GSa/s | MSO8000 datasheet |
| Max. waveform capture rate | 600 Kwfms/s | rigolna.com |
| Digital channels | 16 (opt) | rigolna.com |
| Display | 10.1-inch capacitive multi-touch | MSO8000 datasheet |
| Interfaces | USB Host & Device, LAN (LXI), HDMI, Trig out | MSO8000 datasheet |
| Country of origin | Malaysia | RIGOL price list |
| Shipping dimensions | 21 × 18 × 15 in | RIGOL price list |
| Shipping weight | 20 lb | RIGOL price list |
RIGOL's own figures, from its data sheets and RIGOL North America's site; RIGOL's data sheet is the full reference. Documents: RIGOL's series page.
CH3In the box, and what it is for
What's in the box
- 4 Passive Probes
- RP6150A - qty. 2 for MSO8104/MSO8204
- FacePlate
- Calibration Certificate
- Power Cord
- USB Cable
Standard accessories as RIGOL lists them; your quote confirms them.
What it's good for
- High-speed digital interfaces and clock jitter.
- RF baseband and fast power-switching edges.
- Mixed-signal debug of FPGA and processor boards.
CH4Questions buyers ask
Which MSO8000 models include active probes?
RIGOL lists two RP6150A active probes with the MSO8104 and MSO8204, in addition to the four passive probes every model includes.
Can I add options to the MSO8074A later?
Yes. RIGOL lists 17 options and software packages for the MSO8000 Series (for example MSO8000-AERO, MSO8000-AUDIO, MSO8000-AUTO, MSO8000-AWG). Add them to your quote now or ask about an upgrade later.
Do you ship the MSO8074A outside the US?
We ship within the USA only (all 50 states, DC and the US territories). Outside the US, send an international inquiry and we can point you to a RIGOL distributor in your country.
CH1Request a quote for the MSO8074A
Options and accessories for the MSO8074A
Options & upgrades (17)
| Part | Description | List price | Quote |
|---|---|---|---|
| MSO8000-AWG | 2 Channel 25MHz Generator | $769 | |
| MSO8000-AERO | MIL-STD-1553 Protocol Trigger and Analysis | $1,099 | |
| MSO8000-AUDIO | I2S Protocol Trigger and Analysis | $1,099 | |
| MSO8000-AUTO | CAN and LIN Protocol Trigger and Analysis | $1,099 | |
| MSO8000-COMP | RS232/UART Protocol Trigger and Analysis | $1,099 | |
| MSO8000-EMBD | I2C and SPI Protocol Trigger and Analysis | $1,099 | |
| MSO8000-FLEX | FlexRay Protocol Trigger and Analysis | $1,099 | |
| MSO8000-JITTER | Real-time Eye and Jitter Analysis | $1,099 | |
| MSO8000-PWR | Power Analysis Measurements | $1,099 | |
| MSO8000A-BW20T30 | Bandwidth Upgrade – 2GHz-3GHz | $2,199 | |
| MSO8000-BND | All Option Bundle (Protocol, AWG, Power, Jitter) | $2,499 | |
| MSO8000-BW6T10 | Bandwidth Upgrade – 600MHz-1GHz | $2,899 | |
| MSO8000A-BW7T15 | Bandwidth Upgrade – 750 MHz-1.5GHz | $3,499 | |
| MSO8000-BW10T20 | Bandwidth Upgrade – 1GHz-2GHz | $3,999 | |
| MSO8000A-BW15T20 | Bandwidth Upgrade – 1.5GHz-2GHz | $4,699 | |
| MSO8000-BW6T20 | Bandwidth Upgrade – 600MHz-2GHz | $6,499 | |
| MSO8000A-BW7T20 | Bandwidth Upgrade – 750MHz-2GHz | $7,099 |
Probes (31)
| Part | Description | List price | Quote |
|---|---|---|---|
| RP3500A | 500 MHz Passive Probe | $231 | |
| RP1300H | 100:1 300 MHz TO 2KV PASSIVE PROBE | $243 | |
| RP6150A | 1.5GHz Passive Probe | $342 | |
| RPL2316 | Standard logic probe for MSO4000 and MSO2000A | $399 | |
| RP1025D | High Voltage Differential Probe, DC-25 MHz, 1400 Vpp | $473 | |
| NFP-3 | Near Field Probe, Requency Range: 30MHz to 3GHz | $499 | |
| RP1010H | High Voltage Probe with 40MHz bandwidth, 10kV max DC voltage, 1000:1 | $524 | |
| RP1050D | High Voltage Differential Probe, DC-50 MHz, 7000 Vpp | $683 | |
| RP1100D | High Voltage Differential Probe, DC-100 MHz, 7000 Vpp | $788 | |
| PHA0150 | 70 MHz 1500 V Differential Voltage Probe | $799 | |
| RP1001C | Current Probe, DC-300 kHz, 100 Apeak | $867 | |
| PHA1150 | 100 MHz 1500 V Differential Voltage Probe | $999 | |
| RP1018H | High Voltage Probe with 150MHz bandwidth, 18kV max DC voltage, 1000:1 | $1,038 | |
| RP7080S | Active single-ended, 800 MHz probe for DS6000 or DS/MSO4000 Series Oscilloscopes | $1,049 | |
| RP1000P | RP1003C/RP1004C/RP1005C probe power supply | $1,560 | |
| PHA2150 | 200MHz, 1500V High Voltage Differential Probe | $1,590 | |
| RP1002C | Current Probe, DC-1 MHz, 100A peak | $1,791 | |
| RP7080 | Active, differential, 800 MHz probe for DS6000 or DS/MSO4000 Series Oscilloscopes | $2,099 | |
| RP7150S | Active single-ended, 1.5GHz probe for DS6000 or DS/MSO4000 Series Oscilloscopes | $2,520 | |
| RP1003C | Current Probe, DC-50 MHz, 50A peak. Requires RP1000P power supply. | $3,408 | |
| RP1005C | Current Probe, DC-10 MHz, 300A peak. Requires RP1000P power supply. | $4,332 | |
| RP7150 | 1.5 GHz Bandwidth Active Probe Kit option for DS6000 Series Oscilloscopes | $4,736 | |
| PCA1030 | 50 MHz, 30 A Current Probe for 7000 & 8000 Series Oscilloscopes | $4,890 | |
| PVA7250 | 2.5GHz Active Differential Probe | $4,899 | |
| RP1004C | Current Probe, DC-100 MHz, 50 A peak. Requires RP1000P power supply. | $4,909 | |
| RP1006C | Current Probe, DC-2 MHz, 500A peak. Requires RP1000P power supply. ≤25mArms noise | $5,490 | |
| PIA1020 | 200MHz optical isolation probe, standard with one 20x attenuator. | $5,499 | |
| PCA1150 | 10 MHz, 300 A Current Probe for 7000 & 8000 Series Oscilloscopes | $5,890 | |
| PCA2030 | 100 MHz, 30 A Current Probe for 7000 & 8000 Series Oscilloscopes | $6,390 | |
| PIA1050 | 500MHz optical isolation probe, standard with one 50x and one 2000x attenuator. | $9,999 | |
| PIA1100 | 1GHz optical isolation probe, standard with one 50x and one 2000x attenuator. | $15,199 |
Accessories (7)
| Part | Description | List price | Quote |
|---|---|---|---|
| ADP0150BNC | 50 Ohm impedance adapter for oscilloscopes or generators | $19 | |
| CB-BNC-BNC-MM-100 | BNC Cable (length 1 meter) | $20 | |
| RPA246 | Power analysis phase difference correction jig | $59 | |
| MSO8000-FPC | MSO8000 Front Panel Cover | $119 | |
| DK-DS6000 | Demo Board for oscilloscopes | $231 | |
| RM6041 | Rack Mount Kit for RSA5, RSA3, DS7000, MSO8000 | $309 | |
| USB-GPIB | USB-GPIB Converter. Connect USB directly to instrument and control it via GPIB. This does not connect to a PC directly | $346 |
Extended warranty (1)
| Part | Description | List price | Quote |
|---|---|---|---|
| MSO8074A (R5-1) | MSO8074A extended warranty, 2 years, option with new product | $792 |
