RIGOL MHO2024
200 MHz 4-Channel 12-bit Mixed Signal Oscilloscope · MHO2000 Series
200MHz, 2GSa/s, 4CH, 12bit oscilloscope
List price $2,999
Quote-only: send the form and we confirm your price, any current RIGOL promotion and the lead time.
Ships within the USA only (50 states, DC, Puerto Rico, Guam, USVI, American Samoa, Northern Mariana Islands). Outside the US? Send an international inquiry
CH1RIGOL MHO2024 at a glance
- 200 MHz of bandwidth on 4 analog channels, plus 16 digital channels.
- 12-bit vertical resolution for small signals riding on large ones.
- Battery-pack power for measurements away from a mains outlet.
- 12-bit resolution with 200 µV/div sensitivity.
- 10.1-inch 1280×800 touch screen and Flex Knob.
- 16 digital channels built in (logic probe sold separately).
CH2RIGOL MHO2024 specifications
| Figure | MHO2024 | Source |
|---|---|---|
| Part number | MHO2024 | RIGOL |
| Brand | RIGOL | RIGOL |
| Series | MHO2000 Series | RIGOL price list |
| Bandwidth | 200 MHz | rigolna.com |
| Analog channels | 4 | rigolna.com |
| Vertical resolution | 12-bit | MHO2000 datasheet |
| Max. memory depth | 500 Mpts | MHO2000 datasheet |
| Max. real-time sample rate | 2 GSa/s | MHO2000 datasheet |
| Max. waveform capture rate | 1 Mwfms/s | rigolna.com |
| Digital channels | 16 | rigolna.com |
| Display | 10.1-inch 1280×800 touch screen | MHO2000 datasheet |
| Interfaces | USB Device & Host, LAN, HDMI | MHO2000 datasheet |
| Country of origin | Malaysia | RIGOL price list |
| Shipping dimensions | 6.1 × 13.2 × 9.3 in | RIGOL price list |
| Shipping weight | 14 lb | RIGOL price list |
RIGOL's own figures, from its data sheets and RIGOL North America's site; RIGOL's data sheet is the full reference. Documents: Datasheet · User manual · RIGOL's series page.
CH3In the box, and what it is for
What's in the box
- 4 Passive Probes
- Calibration Certificate
- Power Cord
- USB Cable
Standard accessories as RIGOL lists them; your quote confirms them.
What it's good for
- Field service and on-vehicle measurements on battery power.
- Power-conversion debugging that needs 12 bits on four channels.
- Mixed-signal embedded debug with protocol decoding.
CH4Questions buyers ask
Does the MHO2000 really run on a battery?
Yes. RIGOL designed it for a battery pack, so it can be charged and used away from a mains outlet. Ask us to confirm the battery part number in your quote.
What comes in the box with the RIGOL MHO2024?
RIGOL lists these standard accessories: 4 Passive Probes, Calibration Certificate, Power Cord, USB Cable.
Can I add options to the MHO2024 later?
Yes. RIGOL lists 7 options and software packages for the MHO2000 Series (for example MHO2000-AEROA, MHO2000-AUDIOA, MHO2000-AUTOA, MHO2000-AWG). Add them to your quote now or ask about an upgrade later.
Do you ship the MHO2024 outside the US?
We ship within the USA only (all 50 states, DC and the US territories). Outside the US, send an international inquiry and we can point you to a RIGOL distributor in your country.
CH1Request a quote for the MHO2024
Options and accessories for the MHO2024
Options & upgrades (7)
| Part | Description | List price | Quote |
|---|---|---|---|
| MHO2000-AEROA | MIL-STD-1553 bus triggering and decoding option | $359 | |
| MHO2000-AUDIOA | I2S audio bus triggering and analysis option | $359 | |
| MHO2000-AUTOA | CAN-FD, LIN bus triggering and decoding option | $359 | |
| MHO2000-FLEXA | FlexRay triggering and decoding option | $359 | |
| MHO2000-PWRA | Power analysis option | $359 | |
| MHO2000-AWG | Built-in dual-channel 50MHz function signal generator option | $529 | |
| MHO2000-BND | BND option - PWRA, AUDIOA, AUTOA, FLEXA, AEROA, AWG | $1,299 |
Probes (16)
| Part | Description | List price | Quote |
|---|---|---|---|
| RP1300H | 100:1 300 MHz TO 2KV PASSIVE PROBE | $243 | |
| RP1025D | High Voltage Differential Probe, DC-25 MHz, 1400 Vpp | $473 | |
| RP1010H | High Voltage Probe with 40MHz bandwidth, 10kV max DC voltage, 1000:1 | $524 | |
| RP1100D | High Voltage Differential Probe, DC-100 MHz, 7000 Vpp | $788 | |
| PHA0150 | 70 MHz 1500 V Differential Voltage Probe | $799 | |
| RP1001C | Current Probe, DC-300 kHz, 100 Apeak | $867 | |
| PHA1150 | 100 MHz 1500 V Differential Voltage Probe | $999 | |
| RP1018H | High Voltage Probe with 150MHz bandwidth, 18kV max DC voltage, 1000:1 | $1,038 | |
| RP1000P | RP1003C/RP1004C/RP1005C probe power supply | $1,560 | |
| PHA2150 | 200MHz, 1500V High Voltage Differential Probe | $1,590 | |
| RP1003C | Current Probe, DC-50 MHz, 50A peak. Requires RP1000P power supply. | $3,408 | |
| RP1005C | Current Probe, DC-10 MHz, 300A peak. Requires RP1000P power supply. | $4,332 | |
| RP1004C | Current Probe, DC-100 MHz, 50 A peak. Requires RP1000P power supply. | $4,909 | |
| RP1006C | Current Probe, DC-2 MHz, 500A peak. Requires RP1000P power supply. ≤25mArms noise | $5,490 | |
| PIA1050 | 500MHz optical isolation probe, standard with one 50x and one 2000x attenuator. | $9,999 | |
| PIA1100 | 1GHz optical isolation probe, standard with one 50x and one 2000x attenuator. | $15,199 |
Accessories (4)
| Part | Description | List price | Quote |
|---|---|---|---|
| ADP0150BNC | 50 Ohm impedance adapter for oscilloscopes or generators | $19 | |
| CB-BNC-BNC-MM-100 | BNC Cable (length 1 meter) | $20 | |
| RM6051 | Thunderbird Platform Rack Mount Kit | $259 | |
| BatHolder350 | Battery compartment | $1,099 |
Extended warranty (1)
| Part | Description | List price | Quote |
|---|---|---|---|
| MHO2024 (R5-1) | MHO2024 extended warranty, 2 years, option with new product | $234 |
