RIGOL DG6000 Series
4 models, list from $10,899. Compare them, add options and accessories, and request one quote for the lot.
The DG6000 is a high-voltage differential function/arbitrary generator: 2 or 4 differential channels (or 4/8 single-ended), 2.5 GSa/s, 16-bit resolution, up to 1 GHz differential output and ±10 V high-voltage differential signals, with full channel isolation.
Arbitrary memory is 256 Mpts per channel (512 Mpts optional), and Sequence, PRBS, multi-pulse, multi-tone, pattern, IQ and advanced arbitrary modes are standard. It has a 10.1-inch color touch screen and Web Control.
CH1Models
| Model | Max frequency | Channels | Description | List price | Quote |
|---|---|---|---|---|---|
| DG6052 | 500 MHz | 2 | High-voltage differential function/arbitrary waveform generator, 2.5 GSa/s, 500 MHz, 16-bit, 2 differential channels (equivalent to 4 single-ended channels). | $10,899 | |
| DG6102 | 1 GHz | 2 | High-voltage differential function/arbitrary waveform generator, 2.5 GSa/s, 1 GHz, 16-bit, 2 differential channels (equivalent to 4 single-ended channels). | $14,299 | |
| DG6054 | 500 MHz | 4 | High-voltage differential function/arbitrary waveform generator, 2.5 GSa/s, 500 MHz, 16-bit, 4 differential channels (equivalent to 8 single-ended channels). | $18,799 | |
| DG6104 | 1 GHz | 4 | High-voltage differential function/arbitrary waveform generator, 2.5 GSa/s, 1 GHz, 16-bit, 4 differential channels (equivalent to 8 single-ended channels). | $23,399 |
CH2Options and accessories
Options & upgrades (1)
| Part | Description | List price | Quote |
|---|---|---|---|
| DG6000-2RL | 512 Mpts/CH (Max.) Arb Length Upgrade Option | $879 |
Accessories (1)
| Part | Description | List price | Quote |
|---|---|---|---|
| RM6051 | Thunderbird Platform Rack Mount Kit | $259 |
Extended warranty (4)
| Part | Description | List price | Quote |
|---|---|---|---|
| DG6052 (R5-1) | DG6052 extended warranty, 2 years, option with new product | $891 | |
| DG6054 (R5-1) | DG6054 extended warranty, 2 years, option with new product | $1,539 | |
| DG6102 (R5-1) | DG6102 extended warranty, 2 years, option with new product | $1,170 | |
| DG6104 (R5-1) | DG6104 extended warranty, 2 years, option with new product | $1,917 |
